20X440 – 20 MFD 440V Round Motor Run Capacitor | UL Listed, 60,000 Hour Life
$2.69
High-performance 20µf 440V round motor run capacitor with ±5% tolerance, UL listed, and engineered for long-lasting operation in HVAC systems and motors.
50 in stock
The 20X440 – 20 MFD 440V Round Run Capacitor is a durable, high-efficiency capacitor designed for use in HVAC systems and single-phase AC motors. Built with a no-induction winding structure and a metalized polypropylene film, this run capacitor ensures reliable startup and continuous motor operation in demanding environments.
It features excellent heat dissipation, compact size, and high electrical stability, making it ideal for air conditioning units, compressors, and fan motors. The capacitor includes self-healing properties, explosion-proof construction, and is UL Listed (E477014) for safety assurance.
With a rated capacitance of 20 microfarads (µf) and a voltage rating of 440V, it withstands impact currents and delivers strong overload protection, ensuring a long service life of up to 60,000 hours.
Key Features:
-
20µf ±5% motor run capacitor for AC units and HVAC systems
-
Rated for 440V with excellent heat dispersion and stable performance
-
UL Listed (E477014) for electrical safety compliance
-
Compact, round design with strong overload protection
-
Non-PCB, environmentally safer construction
-
Suitable for 50Hz/60Hz single-phase motor operation
Additional information
| Weight | 0.25 lbs |
|---|---|
| Dimensions | 2 × 2 × 3.25 in |
| Part Number | 20X440 |
| Capacitance | 20 µf (Microfarads) |
| Voltage Rating | 440V |
| Shape | Round |
| Tolerance | ±5% (J), ±10% (K) |
| Operating Frequency | 50Hz / 60Hz |
| Working Temperature Range | -13°F to 158°F (-25°C to 70°C) |
| Construction Type | Metalized Polypropylene Film |
| PCB-Free | Yes |
| Expected Life | 60,000 hours |
| Certification | UL Listed – E477014 |
| Application | HVAC, Air Conditioners, Motors |
| Safety Features | Self-healing, Explosion Proof |
